New And Original WGI210AT SLJXR QFN64 Integrated Circuit Manufacturer
Features:
• Small package: 9 x 9 mm
• PCIe v2.1 (2.5 GT/s) x1, with Switching Voltage Regulator (iSVR)
• Integrated Non-Volatile Memory (iNVM)
• Three single port SKUs: SerDes, Copper, Copper IT
• Value Part (Intel® Ethernet Controller I211)
• Platform Power Efficiency
— IEEE 802.3az Energy Efficient Ethernet (EEE)
— Proxy: ECMA-393 and Windows* logo for proxy offload
• Advanced Features:
— 0 to 70 °C commercial temperature or -40 to 85 °C industrial temperature
— Audio-video bridging
• IEEE 1588/802.1AS precision time synchronization
• IEEE 802.1Qav traffic shaper (with software extensions)
— Jumbo frames
— Interrupt moderation, VLAN support, IP checksum offload
— PCIe OBFF (Optimized Buffer Flush/Fill) for improved system power management
— Four transmit and four receive queues
— RSS and MSI-X to lower CPU utilization in multi-core systems
— Advanced cable diagnostics, auto MDI-X
— ECC – error correcting memory in packet buffers
— Four Software Definable Pins (SDPs)
• Manageability:
— NC-SI for greater bandwidth pass through
— SMBus low-speed serial bus to pass network traffic
— Flexible firmware architecture with secure Flash update
— MCTP over SMBus/PCIe — OS2BMC/CEM (optionally enabled via external Flash
| Specifications | |
| Product Attribute | Attribute Value |
| Manufacturer: | Intel |
| Product Category: | Ethernet ICs |
| RoHS: | Details |
| Mounting Style: | SMD/SMT |
| Package / Case: | QFN-64 EP |
| Product: | Ethernet Controllers |
| Standard: | 10/1GBASE-T, 100BASE-TX |
| Number of Transceivers: | 1 Transceiver |
| Data Rate: | 10 Mb/s, 100 Mb/s, 1 Gb/s |
| Interface Type: | PCIe, SerDes, SGMII |
| Operating Supply Voltage: | 900 mV |
| Minimum Operating Temperature: | 0 C |
| Maximum Operating Temperature: | + 70 C |
| Series: | I210 |
| Packaging: | Tray |
| Brand: | Intel |
| Length: | 9 mm |
| Moisture Sensitive: | Yes |
| Product Type: | Ethernet ICs |
| Subcategory: | Communication & Networking ICs |
| Supply Voltage - Max: | 3.465 V |
| Supply Voltage - Min: | 2.97 V |
| Width: | 9 mm |
| Part # Aliases: | 925132 |
| Unit Weight: | 0.140145 oz |
